Model: YT-64
Sample size for processing: 64 * (0.2-0.5) ml, 64 * 2ml, 64 * (7-15) ml, 2 * 25ml, 2 * 50ml
Display method: LCD screen display, convenient and intuitive operation
Feed size: No requirements, adjust according to adapter
Discharge particle size:~5 μ m
Number of grinding platforms:>2
Homogenization speed: 0-70Hz
Working time: 0-9999 minutes, user can set it by themselves
Grinding ball diameter: 0.1-30mm
Grinding ball material: alloy steel, chromium steel, oxide, tungsten carbide, quartz sand, etc
Noise level:<55db
Grinding method: wet grinding, dry grinding, and low-temperature grinding are all available
Adapter material: polytetraethylene or semiconductor
External dimensions: 420 * 330 * 570
Weight: 40kg
- Product Details
- Product manual
Product Usage
The sample weaving grinder is a special, fast, efficient, and multi tube consistent system. This machine is also known as the tissue grinder, rapid tissue grinder, and multi sample tissue homogenizer central speed sample homogenization system. It can extract and purify original DNA, RNA, and egg yolk matter from any source, including soil, plant and animal tissues and organs, bacteria, yeast, fungi, eggs, paleontological specimens, etc.
Product Features
1.Multiple operations with good results: efficient and fast work can complete the grinding of 2X24, 2X48, and 4X96 samples within 1 minute. Save time and effort, with small differences between batches and within batches. The extracted protein is longer than the active nucleic acid fragments.
2. No cross contamination: The sample tube is in a fully enclosed state during the crushing process, and disposable centrifuge tubes and beads can be used. The sample is kept intact inside the tube to avoid cross contamination between samples and external pollution.
3. Easy to operate, with built-in program controller that can set parameters such as grinding time and rotor vibration frequency; Humanized operation interface.
4. Good stability, using vertical oscillation method for more thorough grinding and better stability; During the operation of the instrument, the noise is less than 55dB and will not interfere with other experiments or instruments.
5. Convenient low-temperature operation: When a low-temperature grinding environment is required, the adapter containing the sample can be immersed in liquid nitrogen and cooled for 1-2 minutes. After removal, it can be quickly fixed on the host to start grinding without the need for further freezing treatment, saving liquid nitrogen.
6. Good repeatability: Set the same program for the same tissue sample to achieve the same grinding effect. The working time is short, and the sample temperature will not rise.
